HXY-5 Core Dill Mechanical Transmit Core Drilling Machine

Price:	1000.0~3000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HXY-5

Production Capacity: 50sets /mouth

Delivery Date: 15days

Type: Others

Means of Transport: Ocean,Land,Air

Packing: wooden case

Application: Coal

Brand Name: gold

TPY-30 Drill Rig is a type of shallow-hole drilling machine for Drilling In Soil

Specifications

HXY-5 Core Dill is a mechanical transmit and hydraulic feeding spindle-typecore drilling machine.

APPLICATIONS

HXY-5 Core Dill is a mechanical transmitand hydraulic feeding spindle-type core drilling machine. It is mainly used forcore drilling with diamond bits for the deep-hole exploration of solid mineraldeposit. It can be also used for exploration of engineering geology andhydrological drilling, and even for large hole foundation stakedrilling.

1Appropriate rang of rotation speeds to satisfy the varied demands for drilling.

2Suitable for large diameter core drilling.

3Equipped with water brake.

4Light in weight, easy to disassemble and transport.

5Easy to operate and maintain.

6Low running cost.

7Diesel engine or motor equipped as required.

MAINSPECIFICATIONS

DRILLINGCAPACITY
Core Drilling
Φ50x5.5 Drilling Rod		1500m
Φ60x6 Drilling Rod		1200m
Wire-line Core Drilling
Φ55.5x4.75 Drilling Rod		1600m
Φ71x5 Drilling Rod		1300m
Φ89x5 Drilling Rod		1000m
DCDMA Drilling Rods
DRILLINGANGLE		90-80°
SWIVELHEAD
Spindle I.D.		93mm
Spindle Speed (rpm) (Power 1500rpm)	Forward	78,136, 231, 271, 359, 472, 802, 1246
	Reverse	65,255
Spindle Stroke		500mm
Max. Torque of Spindle		5500N.m
Max. Pressuring Force of Spindle		100kN
Max. Lifting Force of Spindle		135kN
HOIST
Hoist Capacity (Single Rope)		60kN
Lifting Speed (m/s)		0.6, 1.2, 2, 2.3, 3, 4, 6.8,10.6
Wire Rope		Φ18.5mm
Drum Capacity (Six Layers)		120m
HYDRAULICPUMP
Displacement		32L/min
Working Pressure		20MPa
Max. Pressure		25MPa
WATERBRAKE
Working Speed (rpm)		700-1800
Speed (single rope) (m/s)		3-8
Load (single rope) (kN)		45
SKID-TYPEFRAME
Retraction Stroke		460mm
POWERUNIT(Optional)
ElectricMotor Y250M-4		55kW; 1500rpm
Diesel Engine C4110ZG6-15		60kW; 1500rpm
OverallDimensionLxWxH
With Motor		3260X1300X2045mm
With Diesel		3360X1300X2045mm
Weight (without powerunit)		3100kg
Biggest Disassemblypart		450kg
