Core Sample Drilling Rig For Geological drillings of Hydroelectric Power Station manufacturer from China chongqing gold mechanical $electrical equipment co.,ltd

Core Sample Drilling Rig For Geological drillings of Hydroelectric Power Station

Price:	1000.0~3000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land,Air

Packing: wooden case

Application: Coal

Brand Name: gold

Production Capacity: 50sets /mouth

Delivery Date: 15days

Type: Others

drill rig is a multi-function drill rig developed facing drilling grouting hole for hydro-power station

APPLICATIONS:

Thedrillrig is used in tunnel drilling, geological prospecting, also suitable forgeological drillings of building, hydroelectric power-station, highway, roadwayand harbor and drilling pile grouting hole.

FEATURES:

Thedrill has such features as small body, light weight; especially available forconstruction of hydroelectric power-station. It can get two series of speeds bymeans of substitution of one pair of helical gears for otherone.

Technical Specifications

Drill Capacity(m)	50 drill rod	150
	4343 Wire line drillrod	300
spindle speed (r/min)	Forward	81;164;298;334;587;1190
	reverse	98;199
Max torque(Nm)		1110
angle range		0-90°
Max spindle pull force (KN)		45
spindle stroke		500
hoist max lift capacity (singlerope) (KN)		20
oil pump		CB32 gear oil pump
Power unit	diesel engine	295D 13.2KW
	electric motor	YD180L-4/8 17/11KW
drill body weight(excluding power)(Kg)		650
overal dimensions(L×W×H)(mm)		1720×800×1300

CHONGQINGGOLD MECHANICAL & ELECTRICAL EQUIPMENT CO.,LTD

Established in 2009,Gold is a high -techenterprise specializing in design,manufacture and sale of geologicalinstrument.

Gold'sproducts are manufactured stricity in accordance with industrial standard andhave passed through quality and technical standard evaluation as wellasquality inspection. In 2010,Gold passed through ISO9001 International QualitySystem Certification.In July 2010,Gold obtained provincial certification ofhigh-tech enterprise,becoming an excellent supplier with outstanding productquality in China.

Gold's ProductsSpreadAll Over The Word

Provide ProfessionalTechnical Training

Excellent Team AndBest After Sales Service

We are ready toprovide perfect service for you !
