Platinum Detector DZD-6A Multi-Function DC Reisistivity & IP Instrument For Mineral Recources Survey DZD-6A manufacturer from China chongqing gold mechanical $electrical equipment co.,ltd

Platinum Detector DZD-6A Multi-Function DC Reisistivity & IP Instrument For Mineral Recources Survey

Price:	1000.0~3000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DZD-6A

Production Capacity: 50sets /mouth

Delivery Date: 10DAYS

Type: Others

Means of Transport: Ocean,Land,Air

Packing: wooden case

Application: Others

It is used for water detection and non-metallic mineral resources exploration and so on.

MainApplications

Widely used for high-resolution research, tomography and monitoringapplications.
Coal mining gobs, caves of Custer area, geological disasters survey likelandslides other geological disasters.
High resolution engineering geological exploration like factory foundations,highways, bridges, railways, civil engineering, hydrology, engineering,environmental.
For landslides and other geological disaster exploration.
Metal and non-metallic mineral resources exploration and geothermalexploration.

Main Features

Multiple function in one machine: The instrument has four functionsincluding long lead IP instrument, 2D high density resistivity meter, 2Dhigh-density IP instrument, and medium-power short lead transmitter.
Easy for Operation: The instrument adopts all-digital automatic measurement,thus can execute automatic compensation for spontaneous potential, drift andelectrode polarization. By adopting large screen LCD display in Chinesecharacters, more than fourteen types of wiring working mode can be directlydisplayed in high-density measurement mode; in DZD-6A stand-alone mode, ninetypes of electrode arranging methods can be directly displayed; meanwhile,real-time curve display can be realized during working.
Extra-large Storage: In high-density mode, the instrument can store themeasured data at 120,000 measuring points; in DZD-6A stand-alone mode, theinstrument can store the measured data at 4,800 measuring points; there are 22digits at each measuring points, provided with RS-232 serial interface, and thestored data can be directly transferred to the computer by means of appropriatesoftware to carry out digital interpretation for various methods.

TechnicalSpecifications

Measuringunit ( DZD-6A)

Maximum Measuring Voltage: -6000mV~+6000mV
Measuring Voltage Resolution: 0.01 mV
Measuring Voltage Accuracy: (at Vp>10mV)±5%, ±1 digit; (atVp<10mV)±1%, ±1 digit
Suppression on 50Hz Power Frequency: 80dB
Measuring Current: 0~5000 mA
Measuring Current Resolution: 0.01 mA
Measuring Current Accuracy: (at Ip>10mA)±5%, ±1 digit; (at Ip<10mA)±1% ±Letter
Input Impedance ≥50 MΩ
Measured Apparent Polarizability Accuracy: ±1%, ±1 digit
Maximum Power Supply Voltage 900V
Maximum Power Supply Current: 5A
Power Supply Pulse Width: 1~60 sec.
Weight: 8 kg
Volume: 305×200×202mm
